Environment variables in alphabetical order

A B C D E F G H I J K L M
N O PP Q R S T U V W X Y Z

C

CAS_SRV_CANCEL
Determines the cancel regime for service modules loaded by a SEP: the regime affects the request handler upon completion of the service module invocation. The permissible values are:
  • P - physical cancel (the default)
  • L - logical cancel
  • N - no cancel
  • D - deferred cancel
Example:
CAS_SRV_CANCEL=L
CASSPOOL_LOCK_RETRY_COUNT
Category: JES
If errors are experienced by the spool module, the number of times it retries to obtain a record lock can be adjusted using this environment variable.

Syntax

SET CASSPOOL_LOCK_RETRY_COUNT=count

Values

count The number of retries made to obtain a record lock.

Default

If not specified, this variable defaults to 20.

CCITIMEOUT

Allows the specification, in tenths of seconds, of the maximum time out period that will be used with any LSC style application, such as Drag and Drop, SourceConnect, or the Monitor. The maximum value that can be used is 2,147,483,647.

Syntax

SET CCITIMEOUT=value

Default

The default is 1200 (2 minutes).

Example
This example sets the value to 4 minutes:
SET CCITIMEOUT=2400
CCIERRLOG
Specifies the output location and filename of ccierr.log content which tracks first-instance errors reported from the operating systems. CCIERRLOG overrides any entries found in CCI.INI, where the syntax and content is explained in detail.
CCITCP2
Instead of using the CCI Configuration Utility to set the TCP address of the machine running the CCITCP2 registration daemon the environment variable "CCITCP2" can be used instead. This may be useful if you need different processes on the same machine to contact different registration daemons.

Syntax

set CCITCP2=hostname

Parameters

hostname is the TCP hostname or dotted decimal IP address of the machine running the CCITCP2 daemon you wish to contact from that session.

Comments

The environment variable value will always take precedence over any value set using the Configuration Utility. To restore a process to using the value set by the Configuration Utility simply set the environment variable to an empty string, such as

set CCITCP2=

Alternatively, if this environment variable is set system-wide (by creating a system variable in the system environment settings, or by using a CONFIG.SYS file) then this value will always take precedence over any value set using the Configuration Utility.

CCITCP2_PORT
The port that is being used for the registration process.

Syntax

set CCITCP2_PORT=port
Parameters
  • port The port on which the CCITCP2 registration program operates.
CCITCPS
To start a CCI server on a fixed port, you can associate the Server Name with the port value by using the CCITCPS_ environment variable instead of appending the information on the Server Name itself.

Syntax

set CCITCPS_old_server_name=[new_server_name,]{MFNODE=node_name | MFPORT=port_number | MFNODE=node_name, MFPORT=port_number}

Parameters

  • old_server_name is the name of the CCI server
  • new_server_name is the new name to use for the CCI server. If you do not specify a value for new_server_name the server name stays as old_server_name.
  • port_number is the fixed TCP port to use
  • node_name is the network node to use

Note that this will only work if the server application process is started in the same session or process that has this environment variable set.

Example

set CCITCPS_server_name=MFPORT:3000
CCITCPT

If a client is known to be trying to connect to a server with Server Name server_name, and the TCP address and port (e.g. 3000) that the server is using is known, then the client can be made to connect directly to it by setting this environment variable.

Syntax

CCITCPT_server_name=MFNODE:server_hostname,MFPORT:port_number

Note that this can be used instead of setting the client Machine Name value. This is useful if the Machine Name value the client specifies cannot be altered by an application defined method.

Parameters

  • server_name The server to which the client is trying to connect.
  • server_hostname The TCP address.
  • port_number The TCP post number.

Example

CCITCPT_server1=MFNODE:server2,MFPORT:3000
CCITRACE
Part of the process to enable CCI tracing is to specify the degree of information that will be traced, which can be done by setting the CCITRACE environment variable as follows:

Syntax

CCITRACE=[options]
Parameters
  • options Any, or all, of the following:
/F or -F Logs the details of CCI API calls to the trace file. The default is OFF, unless any other trace option is specified, in which case it is always ON.
/P or -P Logs the details of protocol-level calls to the trace file. The default is OFF. If this flag is OFF, then only the details of the CCI user-level API will be traced. If this flag is ON, the level of function tracing can be increased.
/D or -D Logs the contents of all buffers passed to and from the CCI functions. The default is OFF. Data tracing might not be allowed if the application has been coded to prohibit data tracing for security reasons.

The CCI.INI file can also be used to control trace options, but any values specified by the CCITRACE environment variable will take precedence.

CICS_SIT
The name of the SIT used by the region.
Values
  • The name of the SIT that the region uses.
COBCCSIDDIR
In a deployed application that uses CCSID translation tables, COBCCSIDDIR specifies the location in which the translation tables are installed.

Syntax

set COBCCSIDDIR=base-dir

Parameters

base-dir is the base directory containing sub-directories for each translation table.

COBCONFIG

Specifies a run-time configuration file that tailors the run-time configurable options in some way.

Syntax

SET COBCONFIG=pathname

Parameters

  • pathname The name of the COBOL configuration file that tailors the runtime

Comments

If $COBCONFIG is not set then the file $COBDIR/etc/cobconfig is searched for instead.

Example

SET COBCONFIG=/home/mydir/cobconfig
COBCONFIGJVM
Specifies a Java properties file that tailors the run-time configurable options for Java Virtual Machine applications. Use this instead of COBCONFIG in COBOL applications intended for use on a Java Virtual Machine.

Values

  • The location of a properties file.
COBCONFIG.BLOCK
The location of the application configuration file.
COBCPY

Specifies the directory or directories that the Compiler and Animator should search for copyfiles.

Syntax

SET COBCPY=pathname[:pathname]...

Parameters

  • pathname

    A directory that the Compiler and Animator are to search when looking for copyfiles. When more than one pathname is present, a null pathname represents the current working directory.

Example

SET COBCPY=/home/group/sharedcopy::mydir/mycpy

causes the Compiler to search for a copyfile in /home/group/sharedcopy, then in the current directory and finally in ./mydir/mycpy until either the copyfile is found or it can be considered not found.

COBDATA
Specifies one or more locations, separated by ; (Windows) or : (UNIX), in which to search for data files at run time. As long as the file assignment does not contain a sub-path (that is, a string containing \ or /) then the file assignment is appended to each location specified by COBDATA in order to locate the file.
Note: Users modernizing RM/COBOL or ACUCOBOL-GT legacy code can use a sub-path in the file assignment, but only by compiling with the relevant DIALECT or IDXFORMAT values for the respective File Handling systems; setting these values in the File Handling configuration file is not sufficient to achieve this.

Specifies the directory or directories that the run-time system is to search for data files. Provides you with the facility to map data files globally, thus enabling you to put working data files in a directory whose name is not known until run time.

Syntax

COBDATA=pathname[:pathname]...
Parameters
  • A list of search directories, each item separated by a semicolon. The runtime system is to search these when looking for application data files. When more than one pathname is present, a null pathname represents the current working directory.

Comments

COBDATA affects the compiler and other utilities. During compilation, for example, program source is regarded as a data file by the compiler. If you intend to use any COBOL development system utilities, we recommend that the COBDATA value starts with a colon (:).

COBDATA is considered set if there is an environment variable of this name in your environment space, and its value is non-empty.

The full mapping order for files is:

  1. Any dd_ environment mappings
  2. Any ASSIGN TO EXTERNAL mappings
  3. Any COBDATA environment variable mappings

For multiple directory paths specified either in the COBDATA environment variable or a dd_ environment variable, the system searches the first directory specified followed by a slash (/) as a prefix to the user name.

If the filename is not found, or is not readable, the search continues with the next directory until the final directory has been searched. If no file is found, the first directory is used if a file is to be created.

Any dd_ and COBDATA mappings are ignored for any filename that starts with a hyphen () or a slash (/). In addition, it is illegal to have a hyphen in an environment variable name.

When using this facility, you should not use a filename that starts with "COB... "(these are reserved for the COBOL system).

You can use the COBDATA environment variable for files open in any mode (including OUTPUT) and for fixed or variable length files. If you are using indexed files, both the data and index files must be in the same directory.

The COBDATA environment variable affects file deletes, using the rules given here, as well as file opens.

If you intend to use COBOL development system programs, we recommend that you first unset COBDATA, as many of these programs open data files and are thus affected by the value of COBDATA. If you have to set COBDATA, you should include the paths :$COBDIR/dynload/helptbox.lbr and :$COBDIR/dynload/check.lbr at the beginning of the COBDATA value. If you want to see the Animator Help pages, also include COBDIR/dynload/advanim.lbr.

Note: Users modernizing RM/COBOL or ACUCOBOL-GT legacy code can use a sub-path in the file assignment, but only by compiling with the relevant DIALECT or IDXFORMAT values for the respective File Handling systems; setting these values in the File Handling configuration file is not sufficient to achieve this.

Example

SET COBDATA=:demo:/home/data:progs

causes COBDATA to be set to instruct the runtime system to search for data files in the current directory, then in the directory ./demo, then in the directory /home/data and finally in ./progs.

COBDIR

Specifies the directory where the required Micro Focus COBOL system is installed. Many of the COBOL system components and utilities require and use this information. If the COBDIR environment variable is not set then the COBOL system acts as if it had been set to the default COBOL system directory.

Syntax
SET COBDIR=pathname

Parameters

  • pathname The directory that contains the required Micro Focus COBOL system software.

Comments

The Micro Focus COBOL system is normally installed in the default COBOL system directory and so does not require COBDIR to be set. COBDIR only needs to be set when your COBOL system has been installed in a different directory such as when more than one version of the COBOL system is available at the same time.

Example

SET COBDIR=/home/products/cobse20

This causes the Cob utility to search the directory /home/products/cobse20 for the Micro Focus COBOL system software.

COBJVM

Specifies which Java Virtual Machine (JVM) to load.

Syntax
SET COBJVM=platform_nnn

Parameters

platform_nnn where

platform is a threecharacter code that indicates the platform on which you are running Server Express, for example:
  • ibm IBM AIX
  • unx SCO UnixWare
  • sun Oracle SPARC
nnn indicates the version of the JVM, for example:
  • 122 Version 1.2.2
  • 130 Version 1.3.0

Comments

You might need to set COBJVM if you are developing distributed applications with both COBOL and Java components.

Example

SET COBJVM=ibm_122
COBKEYTIMEOUT

Specifies the maximum elapsed time, in tenths of a second, for the connected terminal to transmit any valid escape sequence to the runtime system.

When a terminal key is depressed, the terminal might send in response a single character or a group of characters to the runtime system. Typically, such a group of characters starts with an escape character and the group of characters is known as an escape sequence. A terminal might send an escape sequence for one depression of a function key. It might also send the same sequence of characters for a depression of the Escape key followed by the depression of one or more alphabetic or numeric data keys. The only difference apparent to the runtime system is the interval between the arrival of each character; the user cannot type as fast as the escape sequence is generated by the terminal.

If a terminal is connected over a network that sends the characters to the runtime system in discrete packets, then the network can alter the intervals between each character arriving at the runtime system. COBKEYTIMEOUT is available to help compensate for typical network delays so the runtime system identifies escape sequences correctly.

Syntax

SET COBKEYTIMEOUT=n

Parameters

n A number in the range 1 through 126 that represents the maximum elapsed time required for a terminal to transmit any valid escape sequence to the runtime system over the line or network connection. On encountering a lone Escape character, the runtime system waits n tenths of a second before assuming that the character does not introduce an escape sequence. The runtime system calculates an appropriate default value for n from the baud rate of the terminal.

COBLANG
The language environment in which your COBOL program runs.
Values
  • A COBOL language environment (LE) value.
COBLPFORM
This configuration variable is used to define and print to printer channels C01-C12. Specify the line numbers for each channel with the COBLPFORM configuration variable. Null entries are ignored. Those channels that have line number zero, function-names S01-S052, CSP, or are undefined, are set to line 1.

Example 1:

COBLPFORM 1:3:5:7:9:11:13:15:17:19:21:23

In this example C01 equals 1, C02 equals 3, and so on.

Example 2:

COBLPFORM :3::5: :9

In this example, C01 equals 3, C02 equals 5, C03 equals 1, and C04 equals 9. You can specify only a single line number for each channel.

In example 2 above, channels C05 - C12 are undefined. If a print statement specifies channel C05 - C12, the line is printed at line 1. In addition, in the example shown, C03 equals 1 because its value is a space and therefore undefined.

Any WRITE BEFORE/AFTER PAGE statements cause positioning to be at line 1. Each line advance increases the line number by one. A request to skip to a line number less than or equal to the current line causes a new page to begin. The appropriate number of line feeds are then generated.

COBMAINSTACK
Note: This variable applies to native COBOL applications on UNIX, and Enterprise Server on both Windows and UNIX.

This variable is used to specify the size of the main stack.

Syntax

SET COBMAINSTACK=n

Parameters

n - The size, in bytes, of the stack.

Comments:

The main stack size defaults to three times the size of a threaded stack. The size of a threaded stack is either specified when the stack is created (using CBL_THREAD_CREATE), or it defaults to 160KB for a 32-bit application or 320KB for a 64-bit application.

You might need to set COBMAINSTACK in any of the following circumstances:

  • If you are deploying OO COBOL Enterprise JavaBeans (EJBs) to WebSphere on the AIX platform.
  • If you are using the multi-threaded run-time system.
  • If you have IF STATEMENTS with a very large number of ELSE clauses.
  • If you have a large amount of local-storage data.
COBPATH

Specifies the directory or directories that the runtime system is to search for dynamically loadable .int and .gnt files, or callable shared objects.

Syntax

SET COBPATH=pathname[:pathname]...

Parameters

pathname A list of search directories, each item separated by a semicolon, that the runtime system is to search for a dynamically loadable program (.int, .gnt or callable shared object) file. When more than one pathname is specified, a null pathname represents the current working directory.

Example

SET COBPATH=u:/home/mydir/srclib:otherlib
COBPRFDIR
Location of .ipf files created by programs compiled with the PROFILE compiler directive.
Values
  • A list of search directories, each item separated by a semicolon.
COBPRINTER

Specifies the name of a print spooler that is to receive, via its standard input stream (stdin), output from any DISPLAY UPON PRINTER statement.

Syntax

SET COBPRINTER=command-line

Parameters

  • command-line A command line supported by your system and that can be executed by the system shell. Typically, it is simply the name of a print spooler or other executable, but if the shell is escaped when setting the value then any command-line arguments can be used.

Comments

Each DISPLAY UPON PRINTER statement executed by your COBOL program causes a new invocation of command-line. Each invocation receives the data referenced in the DISPLAY statement, and is followed by a system end-of-file condition.

Example

SET COBPRINTER="myspooler -a $TMPDIR\spoolfile"
COBSSL
If using SSL connections specifies the location of the DemoCA directory. If not found, SSLDIR is inspected instead.
COBSW
Specifies the run-time system switch settings for the run-time system to observe when running an application.

Syntax

SET COBSW=[+/-}s...
Parameters

A list of the runtime switches to set or unset.

  • + sets a switch.
  • - un-sets a switch.

Example

SET COBSW=+0+D

This enables runtime switch 0 and the ANSI COBOL debug switch.

CODEWATCH_SRCPATH
The location of source files for the debugger to use if none are found in directories specified when invoking CodeWatch
Values
  • A list of search directories, each item separated by a semicolon.
CODEWATCH_STBPATH
The location of STB files for the debugger to use if none are found in directories specified when invoking CodeWatch.
Values
  • A list of search directories, each item separated by a semicolon.

D

DB2DBDFT
The default database for the DB2 SQL precompiler to process SQL statements against.

Values

  • The location and name of the default database.
DBG_MVSPSKEL
The skeleton JCL for debugging.

E

ENTRYNAMEMAP
Specifies the locations of entry name map files to be used.

Syntax

SET ENTRYNAMEMAP={filename|directory}; ...

Parameters

filename An entry map file.

directory A directory containing an entry name map file. The name of the entry name map file must be mfentmap.dat.

Comments

You must set the entry_name_mapper tunable to enable entry point mapper support.

If ENTRYNAMEMAP is not set, the runtime system searches for an entry name map file called mfentmap.dat in each folder specified by the COBDIR environment variable.

If the runtime system finds more than one entry name map file and same entry point is defined differently in different files, precedence is given to the definition in the entry name map file that was found first. To change the order in which the runtime system finds entry name map files you need to change the order in which the files appear in the COBDIR or ENTRYNAMEMAP environment variable paths.

ES_3270_REMOVE_NULL_COLOR_ATTRIB
When this environment variable is set to Y or y, the extended color attribute set to low-values will not to be sent to the 3270 emulator. This fixes an IBM issues related to Personal Communications (PCOM) which is described at http://www-01.ibm.com/support/docview.wss?uid=swg21461404.

Syntax

ES_3270_REMOVE_NULL_COLOR_ATTRIB=value

Values

  • Y|y

Default

The default screen size is used.

ES_ABORT_PLTPI_ERROR
Enables the user to set the error on which to abort PLTPI processing, bypassing the prompt.
Syntax
ES_ABORT_PLTPI_ERROR=xx
Values

Values for xx can be:

  • YN - Abort on PGMIDERR
  • NY - Abort on ABEND
  • YY - Abort on PGMIDERR or ABEND

Comments

By default, when an error occurs during PLTPI processing, mainframe CICS enterprise servers display a prompt that enables the user to cancel the startup or ignore the error. Set ES_ABORT_PLTPI_ERROR to bypass the prompt and automatically abort the initialization as dictated by the value provided.

ES_ACBLIB
Specifies the locations of the IMS ACB files.

Syntax

SET ES_ACBLIB={pathname

Values

pathname The path location of the IMS ACB files.

Default

If this variable is not set the ACB files are assumed to be in the project directory.

ES_ALLOC_EXPAND
The default value is Y, which expands an environment variable when used to specify an allocation path. Set to N to override this behavior, which is to not expand the variable used in the path.

Syntax

SET ES_ALLOC_EXPAND=value

Values

Y Expands an environment variable used to specify an allocation path.

N Do not expand the variable used in the path.

Default

The default value is Y.

ES_ALLOC_OVERRIDE
The default value is Y, which expands an environment variable when used to specify an allocation path. Set to N to override this behavior, which is to not expand the variable used in the path.

Syntax

SET ES_ALLOC_OVERRIDE=rules-file

Values

rules-file The file path and name of the dataset rules file.

ES_CERT_REG
Specifies the directory in which the cascertreg user certificate utility should store its registrations.
Syntax
SET ES_CERT_REG=pathname
Values

pathname Pathname of the directory where registrations are stored.

Default

By default no directory is specified. In this case it must be specified on the cascertreg command.

ES_CESN_NO_OS390
Overrides the default behavior CESN transaction and the IMS sign-on screen response for invalid user credentials. Default behavior reports "Your userid is invalid" or "Your password is invalid".
Syntax
SET CESN_NO_OS390=value
Values
  • Setting this variable to any value causes CESN and the IMS sign-on screen to produce an invalid credential message instead of a specific invalid user or invalid password message.
Default

Specific invalid user/password messages will be produced.

ES_CICS_SINGLE
Configures CICS so that a user can only log on once.

Syntax

SET ES_CICS_SINGLE=value
Values
  • Y|y A user can only log on once.
Default
Not set: A user can log on multiple times.
ES_CLASS_XPCT
Controls the CICS PCT resource class.
Syntax
ES_CLASS_XPCT=value
Values
  • Yes: ACICSPCT is the default PCT class
  • No: Security for PCTs will be bypassed
  • classname: Overrides the default PCT class ACICSPCT with Aclassname
Default
ACICSPCT is the default PCT class.
ES_CLASS_XCMD
Controls the CICS CMD resource class.
Syntax
ES_CLASS_XCMD=value
Values
  • Yes: CICS CMD is the default CMD class
  • No: Security for CMDs will be bypassed
  • classname: Overrides the default CMD class CICSCMD with Cclassname
Default
CICS CMD is the default CMD class.
ES_CLASS_XDCT
Controls the CICS DCT resource class.
Syntax
ES_CLASS_XDCT=value
Values
  • Yes: DCICSDCT is the default DCT class
  • No: Security for DCTs will be bypassed
  • classname: Overrides the default DCT class DCICSDCT with Dclassname
Default
DCICSDCT is the default DCT class.
ES_CLASS_XFCT
Controls the CICS FCT resource class.
Syntax
ES_CLASS_XFCT=value
Values
  • Yes: FCICSFCT is the default FCT class
  • No: Security for FCTs will be bypassed
  • classname: Overrides the default PCT class FCICSFCT with Fclassname
Default
FCICSFCT is the default FCT class.
ES_CLASS_XJCT
Controls the CICS JCT resource class.
Syntax
ES_CLASS_XJCT=value
Values
  • Yes: JCICSJCT is the default JCT class
  • No: Security for JCTs will be bypassed
  • classname: Overrides the default JCT class JCICSJCT with Jclassname
Default
JCICSJCT is the default JCT class.
ES_CLASS_XPPT
Controls the CICS PPT resource class.
Syntax
ES_CLASS_XPPT=value
Values
  • Yes: MCICSPPT is the default PPT class
  • No: Security for PPTs will be bypassed
  • classname: Overrides the default PPT class MCICSPPT with Mclassname
Default
MCICSPPT is the default PPT class.
ES_CLASS_XPSB
Controls the CICS PSB resource class.
Syntax
ES_CLASS_XPSB=value
Values
  • Yes: PCICSPSB is the default PSB class
  • No: Security for PSBs will be bypassed
  • classname: Overrides the default PSB class PCICSPSB with Pclassname
Default
PCICSPSB is the default PSB class.
ES_CLASS_XRES
Controls the CICS DOCTEMPLATE resource class.
Syntax
ES_CLASS_XRES=value
Values
  • Yes: RCICSRES is the default RES class
  • No: Security for DOCTEMPLATEs will be bypassed
  • classname: Overrides the default RES class RCISRES with Rclassname
Default
RCISRES is the default RES class.
ES_CLASS_XTST
Controls the CICS TST resource class.
Syntax
ES_CLASS_XTST=value
Values
  • Yes: SCITST is the default TST class
  • No: Security for TSTs will be bypassed
  • classname: Overrides the default TST class SCITST with Sclassname
Default
SCITST is the default RES class.
ES_CLASS_XTRAN
Controls the CICS TRAN resource class.
Syntax
ES_CLASS_XTRAN=value
Values
  • Yes: TCICSTRN is the default TRAN class
  • No: Security for TRANs will be bypassed
  • classname: Overrides the default TRAN class TCICSTRN with Tclassname
Default
TCICSTRN is the default TRAN class.
ES_CLUSTER
Identifies a region as participating in an Enterprise Server Cluster. Mandatory for all regions in a cluster.
Syntax
ES_CLUSTER=ON
Values
  • Any
Default
If this is not set, the region will not participate in an Enterprise Server Cluster.
ES_CLUSTER_ISC_TRACE
Enables tracing on the Enterprise Server Cluster ISC listeners.
Syntax
ES_CLUSTER_ISC_TRACE=value
Values
  • Any
Default
If this is not set, there is no tracing of Enterprise Server Cluster ISC listeners.
ES_CLUSTER_LISTENER_PORT_TO_USE
This variable enables you to use a specific port for a listener of the cluster.
Syntax
ES_CLUSTER_LISTENER_PORT_TO_USE=port
Values
  • port A port number
Default
If this is not set, ES Cluster listeners will use ephemeral ports.
ES_CONSOLE_LOG (deprecated)
Sends console messages to the Windows Event Log.
Note: ES_CONSOLE_LOG is deprecated, and provided for backward compatibility only. We recommend that you use MFDS configuration options instead.
Syntax
ES_CONSOLE_LOG=port
export ES_CONSOLE_LOG
Values

Can be any combination of the following:

  • I - Send informational messages to the Windows Event Log.
  • W - Send warning messages to the Windows Event Log.
  • E - Send error messages to the Windows Event Log.
  • S - Send severe messages to the Windows Event Log.
Default
If this is not set, console messages are not sent to the Windows Event Log.
ES_CSKL_NO_MSG_CONSOLE
Stops CSKL writing messages to console.log
Syntax
ES_CSKL_NO_MSG_CONSOLE=value
Values
  • Any - CSKL messages are not written to the console log.
Default
If this is not set, CSKL messages are written to the console log.
ES_CWS_WSBIND_COMP
Enables support of CICS applications that use COMP declarations.
Values
  • Y - Enables support for COMP declarations.
  • N - Does not enable support for COMP declarations.
Default

N

ES_DB_FH

Enables or disables database file handler support. This is required if your data files are stored in a datastore, or your enterprise server region stores some of its resources in a database; see Micro Focus Native Database File Handling and Enterprise Server Region Database Management for more information.

Syntax

SET ES_DB_FH=value

Values

  • Y|y|true - file handling is directed through the Micro Focus Database File Handler (MFDBFH).
  • N|n|false - database file handler support is disabled.

Default

Database file handler support is disabled.

ES_DB_SERVER

Specify the name of the database server to be used for region database operations.

There also needs to be a corresponding <server> entry for the database server within the configuration file specified by the MFDBFH_CONFIG environment variable. <dsn> entries for the region, cross-region and master databases must also be specified in the configuration file to enable use of region database operations.

Syntax

SET ES_DB_SERVER=server-instance

Values

server-instance is the name of a valid database server instance. For example, set ES_DB_SERVER=(local)\SQLEXPRESS.

Default

Not set.

Example

Using the example above, you would be required to have something similar to that below in your database configuration file:

<?xml version="1.0" encoding="utf-8"?>
<datastores usevault="false">
   <server name="(local)\SQLEXPRESS" type="sqlserver" access="odbc">
       <dsn name="SS.MYMASTER" type="database" dbname="master"/>
       <dsn name="SS.CAS.ESDEMO" type="region.cas" region="ESDEMO" feature="all"/>
       <dsn name="SS.CAS.CROSSREGION" type="crossregion.cas"/>
   </server>
</datastores>
ES_DDBG_PORT_RANGE
A range of ports to use for dynamic debugging.
You specify a range of port numbers using either a hyphen or a comma.

If you use a hyphen, the values you specify are the start and the end of the port range, and the second port number must be greater than the first.

If you specify a comma, the values you specify are the start of the port range and the number of ports available from the start of the range.

Syntax
ES_DDBG_PORT_RANGE=value
Values
  • low_port-high_port

    or

  • low_port,number_of_ports
Default
If this is not set, dynamic debugging will use random ports.

Examples

The following definition specifies that ports 8001 through 8040 are to be used:

ES_DDBG_PORT_RANGE=8001-8040

The following definition specifies the same ports but using a different format:

ES_DDBG_PORT_RANGE=8001,40
ES_DISABLE_DFLTUSR_SIGNON
Disables the default user ("mfuser") signon when invoking ES Monitor & Control (ESMAC).
Syntax
ES_DISABLE_DFLTUSR_SIGNON=value
Values
  • Y or y Having logged on to ES administration via your MFDS internal security account, you no longer receive the auto logon as "mfuser" when accessing ESMAC.
Default
If this is not set, mfuser will be used as the default user to sign in to ESMAC.
ES_DFS3650
The default transaction to execute or MOD file to be displayed after successfully signing on to IMS. You specify these by setting environment variables prior to the start of the region: ES_DFS3650 - set to MOD if a MOD file is to be sent, or TRX if a TRANSACTION is to be executed. If you set to MOD, ES_MOD3650 needs to be set to the name of the MOD you want to display. If you set to TRX, ES_TRX3650 needs to be set to the name of the transaction.
Syntax
ES_DFS3650=value
Values
  • MOD - ES_MOD3650 needs to be set to the name of the MOD you want to display
  • TRX - ES_TRX3650 needs to be set to the name of the transaction
Default
No default transaction or MOD.
ES_ECI_MAX_RESP
Specifies the maximum expected response size (in bytes) to use when using Micro Focus ECI support to invoke CICS programs. You need to use this environment variable when the amount of data returned from the CICS programs is approximately more than twice the size of the input data, which is sometimes the case when using channels and containers where the back-end program creates or enlarges containers.
Syntax
ES_ECI_MAX_RESP=value
Values
  • Maximum value is 16777215.
Default
If this is not set, the maximum expected response size is calculated dynamically by multiplying the size of the TIOA by 2.
ES_ESM_CMDSEC
Indicates whether CICS processing honors the CMDSEC option specified on a transaction's PLT definition.
Syntax
ES_ESM_CMDSEC=value
Values
  • YES - CICS overrides the CMDSEC option, and always calls its command security checking routine to issue the appropriate call to the SAF interface
Default
CICS honors the CMDSEC option defined in a transaction's resource definition. CICS calls its command security checking routine only when CMDSEC(YES) is specified in a transaction resource definition.
ES_ESM_IDPW_CASE
Forces the case of user ID and password for single attempt ESM authentication. You use the environment variable with a format ES_ESM_IDPW_CASE=xy, where "x" is the folding option for user ID, and "y" the option for password.
Syntax
ES_ESM_IDPW_CASE=xy
Values

Values for both x and y are:

  • U - Always upper case.
  • L - Always lower case.
  • M - Mixed case and case sensitive

Default

Legacy behavior.

Comments

When this environment variable is set, Enterprise Server will only make one attempt to identify a user presenting the user ID and password as is (M), folded to uppercase (U) or folded to lower case (L). If this environment variable is not set, the legacy Enterprise Server behavior will be used.

For the legacy behavior for CICS, the User ID and the password are used as supplied possibly filtered by the uppercase translation configuration of the sign-on transaction.

For ESMAC and IMS, the legacy behavior is that, first, the user ID and password are used as supplied. If the authentication fails, the user ID is folded to uppercase and used again. If this fails as well, both the user ID and the password are folded to uppercase and then used.

Example

ES_ESM_IDPW_CASE=UM - a single authentication is tried with the user ID folded to uppercase, and the password used as-is.

ES_ESM_PLTPISEC
The level of security checking for PLTPI processing.
Syntax
ES_ESM_PLTPISEC=value
Values
  • NONE - You do not want any security checking on PLT initialization programs.
  • CMDSEC - You want CICS to perform command security checking only.
  • RESSEC - You want CICS to perform resource security checking only.
  • ALL - You want CICS to perform both command and resource security checking.

Default

NONE

ES_ESM_PLTPIUSR
The user id under which PLT programs run during CICS initialization.
Syntax
ES_ESM_PLTPIUSR=userid
Values
  • userid - The userid that CICS is to use for security checking for PLT programs that run during CICS initialization.
ES_ESM_RCF
Determines how RACF is used for command authorization
Syntax
ES_ESM_RCF=value
Values:
  • A Includes options T, C, and S.
  • C Specifies that RACF is to be used for ETO terminal command authorization.
  • N Specifies that no sign-on, transaction, or command authorization is to be performed by RACF.
  • S Specifies that RACF is to be used for static and ETO terminal command authorization. Includes option C.
  • T Specifies that RACF is to be used for sign-on and transaction authorization.
  • Y Includes options T and C.
Default
N
ES_ESM_RESSEC
Indicates whether CICS processing honors the RLS security setting specified on a transaction definition (PCT).
Syntax
ES_ESM_RESSEC=value
Values:
  • ALWAYS - CICS processing always performs resource level security checking irrespective of the RLS security setting on the transaction definition.
Default
If this is not set, the RLS security setting of a transaction will be honored. That is, resource level security checking is performed only when the RLS security checkbox is marked in the PCT definition.
ES_ESM_SECPRFX
Indicates whether CICS processing prefixes the resource names when making security queries.
Syntax
ES_ESM_SECPRFX=value
Values
  • NO - No prefixes are used.
  • YES - Resource names are prefixed with the CICS region user ID.
  • prefix - A string to be used as the prefix for resource names. It can be 1 to 8 upper case alphanumeric characters and it must start with an alphabetic character.
Default
NO
ES_ESM_XUSER
Indicates whether CICS processing performs surrogate user checks.
Syntax
ES_ESM_XUSER=value
Values
  • NO - No surrogate user checking is performed.
  • YES - Perform surrogate user checking wherever such checks are permitted.
Default
YES
ES_ESMAC_DISP_MAX_OVERRIDE
Limits the number of lines shown when viewing an individual catalog entry in the ESMAC catalog view or when viewing a SYSOUT file from the job list view.
Syntax
ES_ESMAC_DISP_MAX_OVERRIDE=value
Value
  • An integer number denoting how many lines to display. The maximum number is 99999.
Default
10000
ES_EUSA_SIZE
Sets the size of the extended user storage area, allowing large memory allocations to be set using the GETMAIN SHARED command. Set this variable to a numeric value representing the number of MB.
Syntax
ES_EUSA_SIZE=number
Values
  • Number of MB for the extended user storage area.
Default
16 MB
ES_GLM
If this variable is set, it identifies the region as an Enterprise Server Cluster Global Lock Manager (GLM).
Syntax
ES_GLM=value
Values
  • Any value sets the variable.
Default
If this variable is not set, the region is not a Global Lock Manager (GLM).
ES_GLM_TIMEOUT
The duration in which a submit request to an Enterprise Server Cluster Global Lock Manager (GLM) can be retried before disabling the connection permanently.
Values
  • n seconds.

This variable only applies to the region within an Enterprise Server Cluster designated as the GLM.

Syntax
ES_GLM_TIMEOUT=secnds
Values
  • The number of seconds within which a request can be retried..
Default
120 seconds.
Comments
Only applies to the region within an Enterprise Server Cluster designated as the GLM.
ES_HOSTNAME_TO_USE
In an Enterprise Server Cluster, if a machine uses more than one network card, you may need to set this variable to indicate which hostname MFCS should use.
Syntax
ES_HOSTNAME_TO_USE=hostname
Values
  • The relevant hostname.
ES_HSF_CFG
Enables you to configure a number of additional fields to appear in the HSF record displayed in the .csv file (cashsf-a.csv or cashsf-b.csv).

Syntax

SET ES_HSF_CFG=cfg-options

Parameters

Define cfg-options using the following syntax:
field_name=value;[field_name=value;]...
using the following values:
Field name Range Default
CUSTOM 0-5 0
CICSF 0-20 5
TSQ 0-20 5
TDQ 0-20 5
Note: If a field is not explicitly set, or the value specified is out of range, the default value for the field is used.

For example: ES_HSF_CFG=CUSTOM=2;CICSF=10;TSQ=32 generates 2 custom fields, 10 CICS file fields, 5 TSQ fields and 5 TDQ fields.

Custom fields are written to using the ES_WRITE_CUSTOM_HSF library routine.

ES_IMS_BASIC_CHKP_OPT
When set to 1, enables a basic checkpoint call to process as if a SYNC call had been issued. The default is 0 (zero).
ES_IMS_BYPASS_OTMA_DEST_RES
By default, a CHNG call issued from an OTMA- or IMS Connect-submitted transaction assumes that the destination is the OTMA client. In some circumstances, the previous behavior of assuming a non-OTMA client is desirable. To use the previous behavior, set this environment variable to Y.

Values:

  • Y
  • N (default)

Example

ES_IMS_BYPASS_OTMA_DEST_RES=Y
ES_IMS_CANCEL_MODE[6]
Controls the caching of IMS binaries.

Syntax

SET ES_IMS_CANCEL_MODE=<cancel-mode>

Values

Permissible values for <cancel-mode> are:
  • P - Performs a physical cancel; every transaction will have new-copy behavior. This option is the default behavior, but is the poorest performing of the options.
  • L - Performs a logical cancel. This gives the best performance of the options, but can only be used it there is only one DLITCBL entry point in an MPR.
  • D - Performs a deferred cancel, which will yield the same behavior as a logical cancel when the MPR services the same MPP back-to-back. It will behave as P (physical cancel) when the transaction changes.
ES_IMS_CONFIG
The IMS TM parameters.
ES_IMS_DB_COMMIT_FLUSH
When set to 0 (zero), forces the flushing of database buffers to disk on CLOSE only (default). When set to 1, forces the flushing of database buffers to disk on COMMIT only.
ES_IMS_DB_TLOG_WRITETHRU
When set to 0 (zero), forces the flushing of TLOG buffers to disk on COMMIT only (default). When set to 1, forces the flushing of TLOG buffers to disk on all database I/O.
ES_IMS_DEADLOCK_WAIT
Time in milliseconds to wait before checking for a deadlock. The default is 1000 (1 second).
ES_IMS_DIAGNOSE
Marks IMS TM as diagnose mode only for IMSMSGQ.

When set to Y, the Transaction Manager (TM) works in diagnostic mode only, and no activity key points are written to the message queue.

CAUTION:
Set ES_IMS_DIAGNOSE only when advised to do so by Micro Focus.
ES_IMS_DOSVS_PCB
Emulates DOS/VSE PCB address alignment for EXEC DLI programs.
ES_IMS_DUMP_ON_DEADLOCK
Creates a system dump when a deadlock is detected.
ES_IMS_DUMP_ON_TIMEOUT
Creates a system dump when a lock timeout occurs.
ES_IMS_EXITPATH
The location of compiled code that contains segment, field, and/or print exits.
ES_IMS_FORCE_SIGNON
Enables a user to force a sign-on to IMS on the current terminal and sign off from other terminals.
ES_IMS_GOTO_CICS_ON_SIGNOFF
Returns to CICS upon logging off or timing out, rather than returning to the IMS sign-on screen, which is the default behavior.
ES_IMS_IBMPLATFORM
Sets the emulation for the IMS run-time. Valid values are: M (for MVS) or D (for DOSVS). The default value is M.
Note: This variable is rarely required to be changed from its default, even for the majority of DOSVS users.
ES_IMS_IMSID
Allows the user to specify the IMS System ID returned to the AIBTDLI INQY ENVIRON call.
ES_IMS_INQY_OTMA
Returns TPIPE, MBR, SYNC, and MSYNC to an INQY call.
ES_IMS_INQY_UNKNOWN
Value returned to an INQY call.
ES_IMS_IRLM
Enables Internal Lock Resource Manager (IRLM) locking. IRLM locking more closely parallels mainframe IMS database DB locking behavior, reducing data constraint and potential for deadlock.
ES_IMS_LOCALDLI
Deprecated. See IMS Database Locking. When set to 1, directs batch program execution to process all IMS DB calls entirely in the JES initiator providing significant performance improvement. All IMS DB control processes accessed from the batch program must be stopped before execution because they become exclusively owned by JES until the program completes.
ES_IMS_LOCK_TIMEOUT
The number of seconds during which IMS DB control continues to retry a locked record before timing out. Valid values are 0 to 65535. The default is 30 seconds; a value of 0 indicates an indefinite wait time.
ES_IMS_LOCK_RETRY_DELAY
The IMS DB lock retry delay in milliseconds.
ES_IMS_LTERM_PREFIX
Specify a one- to four-character LTERM prefix alternative to the default (OTMA) to use when the ES_IMS_SINGLE environment variable is set to N. Use of an alternative prefix to OTMA enables you to exercise control over name conflicts.

Syntax

ES_IMS_LTERM_PREFIX=1to4charprefix

Values

Use up to four characters of your choice. Enterprise Server pads the value specified with numeric digits up to eight characters, enabling the LTERM pool to be expanded from 9999 up to 999999. The pool size is dictated by the number of characters used in the specified prefix. For example, the LTERM pool size for a four-character prefix is 9999; for a three-character prefix is 99999; and so on.

Default

OTMA

Note: The default setting of this environment variable suggests that the LTERMS apply only to OTMA clients; however, this is not the case. LTERMS can also be applied to second and subsequent 3270 user connections.
ES_IMS_LU_LTERM
Determines the value of the LTERM literal returned by the MFS system. Valid values are: Y to return the LU name; N to return the user ID.
ES_IMS_MESGQ
Sets the configuration for the IMS TM message queue. The ES_IMS_MESGQ environment variable is generated and set automatically by Enterprise Server, and is reserved.
Restriction: Manually set this variable only when advised to do so by Micro Focus Customer Care.
ES_IMS_MESGQ=[ds-file-name];max-blocks;buffer-count;start-control;[cushion-size]
ds-file-name
An alternative data store file to the default, which is IMSMESGQ.dat.
max-blocks
Data store size limit represented as the number of 64K blocks. Default is 4.
buffer-count
The number of 64K buffers to allocate. Default is 2.
start-control
A flag that sets the start behavior as follows:
Y Cold start the resource definitions. Default.
S Cold start the statistics and resource state information.
Q Cold start the data store (system cold start).
cushion-size
The size of the cushion to be reserved for graceful lack-of-space behavior, represented as a number from 0 to 255. The specified number represents 32 times the actual percentage of max-blocks reserved for emergency use. The default is 4 (a raw value of 128).
ES_IMS_OPEN_TIMEOUT
Defines the wait period in seconds during which IMS retries the opening of a database file that is in use by another task. Default is 30 seconds.
ES_IMS_OTMA_DEST
Each specified destination consists of the destination name, the NONOTMA keyword, and the LU type (LU1 or LU3) separated by commas. Each destination definition is separated by a semi-colon.
IMS_OTMA_DEST=printerName,NONOTMA,LUtype[;...]
ES_IMS_PATH
The location of compiled COBOL applications.
ES_IMS_PLI_INDIRECT_PCBADDR

Determines whether the PL/I program converts the PCB address list from a direct to an indirect addressing technique. Set the variable to one of the following values:

D
If the main program is a PL/I program, PCB addresses are converted from a direct to an indirect addressing technique.
Y
Always converts addresses from a direct to an indirect addressing technique as long as the PSB language is set to PL/I.
N
Never converts addresses from a direct to an indirect addressing technique.

The default is D (dynamic).

ES_IMS_RELEASE
Allows the user to specify the IMS Release returned to the AIBTDLI INQY ENVIRON call.
ES_IMS_REGION
Allows the user to specify the IMS Region returned to the AIBTDLI INQY ENVIRON call.
ES_IMS_ROLLBACK
Enables automatic Backward Recovery; enabled by default.
ES_IMS_ROLLFORWARD
Enables or disables Forward Recovery logging. Valid values are: Y to enable; N to disable. The default is N.
ES_IMS_SINGLE
Enables or disables functionality that allows a single user to sign on to multiple LUs simultaneously.

Values

Y
Disables multiple sign-on functionality.
N
Enables multiple sign-on functionality.

When ES_IMS_SINGLE is set to N, and a user attempts to sign on to an LU using a sign-on that is currently active at another LU, IMS Transaction Manager (TM) assigns a temporary LTERM to the user and LU using a name constructed from the ES_IMS_LTERM_PREFIX setting followed by a numerical value totalling eight characters (see the IMS_LTERM_PREFIX entry in this topic for details). The temporary LTERM is the destination for the user and LU irrespective of activity at other LUs controlled by the user. When a user disconnects from an LU that is served by a temporary LTERM, the LTERM is returned to the temporary pool for reuse.

Also when ES_IMS_SINGLE is set to N, the execution of /dis USER all returns a sub-list for each user that shows all active connections. These connections persist throughout a session, and are dynamically recreated during a warm start.

Default

Y

Note: No KEYPOINT activity is associated with the use of ES_IMS_SINGLE.
ES_IMS_SPARSE_EXIT_LANG
Indicates the language of the IMS DB secondary index sparse routines.
  • C (for COBOL)
  • A (for Assembler)
By default, this variable is not set (sparse exits are disabled).
ES_IMS_SUPPORT
Enables IMS support.
ES_IMS_TLOG_COMPRESS
When set to 0 (zero), disables compression of the Backward Recovery TLOG file. When not compressed, the file contains only the information required to recover databases. The default is enabled.
Note: When enabled, Enterprise Server reclaims space in the file when information becomes obsolete.
ES_IMS_TLOG_FLUSH
When set to 1, forces the frequent flushing of TLOG and database buffers to disk.
Warning: Depending upon the number of database updates, the frequency of commits, and other computer activity, use of ES_IMS_TLOG_FLUSH could result in significant performance degradation.
Note: This environment variable is deprecated. Use ES_IMS_DB_TLOG_WRITETHRU to flush TLOG buffers and ES_IMS_DB_COMMIT_FLUSH to flush database buffers.
ES_IMS_TLOG_MAXSIZE
Maximum size of the IMS DB transaction logging file in bytes. The default is 4GB or h"FFF00000".
ES_IMS_TLOG_PATH
The location of IMS DB transaction logging files. The default is the Enterprise Server system directory.
Note: Once created, you can move log files, but do not rename them. Before attempting to recover a database, all log files must reside in the directory specified by ES_IMS_TLOG_PATH.
ES_IMS_TLOG_THRESHOLD
Threshold size of the IMS DB transaction logging file. When reached, the current TLOG file is closed and a new TLOG file created for subsequent transactions. The default is 2GB or h"7FFFFFFF".
ES_IMSCFG
The location of the IMS configuration files IMSCONFG.DAT.
ES_IMSDAT
The location of IMS DB data files.
ES_IMSLIB
The location of DBDGEN2.DAT, DBDGEN2F.DAT and PSBGEN3.DAT files.
ES_INQFILE_RETURN
Modifies EXEC CICS INQUIRE FILE behavior for catalogued files.

Syntax

set ES_INQFILE_RETURN=value

Parameters

  • DSN - the DSN is returned. For an alternate file the BASEDSNAME will be the DSNAME of the BASE file.
  • PCN - the PC name of the file (truncated to 44 characters) is returned if the file is open, or if FCT fixup has been performed. Otherwise the dataset name is returned.

Default

PCN

ES_JESYSMSG_OUTPUT
The status of the system messages spool files (JESYSMSG) is set to Output, rather than Out Hold.

Syntax

SET ES_JESYSMSG_OUTPUT==Y|N

Values

  • Y All job messages will have the status as Output, but will only actually print (either physically or logically) if the MSGCLASS of the job matches one of the sysout classes defined to an active printer.
  • N Messages are set to Out Hold

Default

The default is N.

ES_JES_BYTES
Maximum number of bytes to output in a job before taking the action specified (either cancelling the job, cancelling the job and dumping memory contents, or issuing a warning message)
ES_JES_BYTES=NUMBER | (NUMBER,WARNING | CANCEL | DUMP)
ES_JES_CARDS
Maximum number of cards to output in a job before taking the action specified (either cancelling the job, cancelling the job and dumping memory contents, or issuing a warning message)
ES_JES_CARDS=NUMBER | (NUMBER,WARNING | CANCEL | DUMP)
ES_JES_DELAY_MEM_ENQ [9]
Delays the exclusive enque of a new (not previously existing) PDS member until the file is opened. PDS members are given an exclusive enque at step start.

When used with existing PDS members, the program abends with code S213 when it attempts to access a file and cannot get the exclusive enque.

Syntax

ES_JES_DELAY_MEM_ENQ=Y|N

Default

The default is N.

ES_JES_DISABLE_RESTART_FLUSH
Indicates whether a region's jobs are moved from the Active queue to the Complete queue when a region is restarted
ES_JES_FREE_SSTM_SYSOUT
When set to Y, decreases the amount of memory used when processing CICS spool datasets in an SSTM enterprise server.
ES_JES_LINES
Maximum number of lines to output in a job before taking the action specified (either cancelling the job, cancelling the job and dumping memory contents, or issuing a warning message)
ES_JES_LINES=NUMBER | (NUMBER,WARNING | CANCEL | DUMP)
ES_JES_OUTLIM
Maximum number of lines to output to a particular dataset before calling the user exit, processing any global limits, and then cancelling the job
ES_JES_OUTLIM=NUMBER | (NUMBER,WARNING | CANCEL | DUMP)
ES_JES_PAGES
Maximum number of pages to output in a job before taking the action specified (either cancelling the job, cancelling the job and dumping memory contents, or issuing a warning message)
ES_JES_PAGES=NUMBER | (NUMBER,WARNING | CANCEL | DUMP)
ES_JES_PARM_INIT_LOW
When set to Y, the parameter string passed to a program executed by JCL is initialized to low-values. The default is N, which is to initialize it to spaces.
ES_JES_RESTART
Enables JCL restart processing.
Syntax
ES_JES_RESTART=value
Values
  • Y|y Enables restart processing.
Default
By default JCL restart processing is not enabled.
ES_JES_SPOOL_ORDER
The order in which the spool list is displayed when you first open ESMAC.
Syntax
ES_JES_SPOOL_ORDER=value
Values
  • 1 - Displays the list in descending order by JOBID. Any other value displays it in ascending order.

Default
By default the list is displayed in ascending order by JOBID.








ES_LE370_SUPPORT
Enables support for Language Environment (LE) in CICS applications
Syntax
ES_LE370_SUPPORT=value
Values
  • Y|y Enables LE support.
Default
By default LE support is not enabled.
ES_LEGACY_ECI
Indicates that Enterprise Server must use Micro Focus ECI instead of IBM CTG.
Syntax
ES_LEGACY_ECI=value
Values
  • Y|y Micro Focus ECI is used.
Default
By default IBM CTG is used.
ES_MAX_CATALOG_LINES
Restricts the number of entries displayed in ESMAC catalog view.
Syntax
ES_MAX_CATALOG_LINES=number
Values
  • number The number of lines to display. The maximum is 99999.
Default
The default is 5000.
ES_MEM_STRATEGY
Selects the types of memory processes supported.
Note: Note that memory strategy can also be set via the memory_strategy runtime tunable.
ES_MFASM_SUPPORT
Enables Assembler support when running CICS server regions.
Syntax
ES_MFASM_SUPPORT=value
Values
  • Y|y

    Assembler supported for CICS server regions.

  • N|n

    No Assembler supported for CICS server regions.

Default
By default Assembler support is not enabled.
ES_MFSLIB
The location of the control blocks generated by the MFS generation program.
Syntax
ES_MFSLIB=pathname
Values
  • pathname The path to the MFS directory.
Default
product_install_dir/etc/ims
ES_MOD3650
The default MOD file to be displayed after a successful sign-on to IMS. See ES_DFS3650.
Syntax
ES_MOD3650=filename
Values
  • filename - The name of the MOD file.
ES_MQ_1PC
Indicates whether the IBM WebSphere MQ switch module ESMQXA should operate in one-phase commit mode. Set this environment variable only when advised to do so by Micro Focus.

Syntax

SET ES_MQ_1PC=value

Values

  • Y|y|T - ESMQXA operates in one-phase commit mode.

Default

By default ESMQXA does not operate in one-phase commit mode.

ES_MQ_LISTENER (deprecated)
Defines one or more WebSphere MQ listeners.
Note: ES_MQ_LISTENER is deprecated, and provided for backward compatibility only. We recommend that you use MFDS configuration instead.

Syntax

SET ES_MQ_LISTENER={QueueManagerName,QueueName,ListenerName}
[,QueueManagerName,QueueName,ListenerName}...
Values

QueueManagerName,QueueName,ListenerName - the characteristics of the listener being defined.

Default

By default, no WebSphere MQ listeners are defined.

ES_MQ_XA
The type of XA structure to use for the two-phase commit XA switch module.

Syntax

SET ES_MQ_XA=value
Values
  • D: use a dynamic XA structure
  • S: use a static XA structure

Default

By default, a dynamic XA structure is used.

ES_OLD_DYN_PDS
Determines the resulting behavior of dynamic PDS members when specified in a JCL DD statement.

Values

Y Enables previous default behavior of cataloging and creating the physical files for dynamic PDS when referenced in a JCL DD statement.

N Physical files for dynamic PDS members are only created and cataloged when created using the JCL utility or by a user program.

Default

The default value is N.

ES_OLD_SEC_TSTD
Prevents security being enforced for TS or TD queues that are not declared in the security repository.
Syntax
SET ES_OLD_SEC_TSTD=value
Values
  • Any value.
Default
By default security is enforced for TS or TD queues that are not declared in the security repository.
ES_OTMA_TIMEOUT
The time in seconds that an OTMA client should wait for an answer. The default value is 120.
Syntax
SET ES_OTMA_TIMEOUT=seconds
Values
  • seconds - The number of seconds to wait. The maximum is 43199.
Default
120 seconds.
ES_PL1_MFFH
Enables Micro Focus File Handler to perform all Open PL/I I/O operations. The default value is "Y". If it is set to "N", then all I/O will be routed to old Liant file handlers.

Syntax

ES_PL1_MFFH=Y|N

Values

Y Micro Focus File Handler is used to perform all Open PL/I I/O operations.

N All I/O is routed to old Liant file handlers.

Default

The default value is Y.

ES_PL1_MFFH_JCL
Enables you to run Open PL/I programs that access JCL data definitions.

Syntax

ES_PL1_MFFH_JCL=Y|N

Values

Y You can run Open PL/I programs that access JCL data definitions.

N Open PL/I programs cannot access JCL data definitions.

Default

The default value is N.

ES_PLI_SUPPORT
Tells the CICS Emulation that it needs to load its subsystem support for PL/I user programs.

Syntax

ES_PLI_SUPPORT=value

Values

  • Y|y - PL/I support is enabled.

Default

PL/I support is not enabled.

ES_PROG_PATH
Set ES_PROG_PATH=Y to display the program's load path in the JESYSMSG and SYSLOG datasets.
Note: This is only applicable for native enterprise server regions.
ES_RLS_FILE_SUPPORT
If a record is locked because a program is doing a read for update, and the application needs to ensure that no other program can access that record, you can set this environment variable to avoid returning a dirty record until the program holding the lock has completed. The timeout in fileshare also needs to be set to 0 using /t 0 in the fileshare configuration file.

Syntax

SET ES_RLS_FILE_SUPPORT=value

Values

  • Y|y - Stops dirty records being returned when a record is locked by another process.

Default

RLS file support is off.

ES_SAM_ESDS
Under VSE, when this is set to Y, opening an OUTPUT of a reusable ESDS file resets the file when the DISP is not specified in the DLBL statement.
ES_SEP_DORMANT_TIME
Allows override of Transient SEP dormant time. Rather than automatically terminating transient SEPs on completion of a stateful request, the server manager allows a period of inactivity before scheduling their termination. This allows new requests to re-use the SEP rather than starting a new instance. This environment variable allows the period of inactivity to be controlled.

Syntax

ES_SEP_DORMANT_TIME=seconds

Values

  • seconds Number of seconds' inactivity.

Default

Transient SEPs are terminated after 2 seconds of inactivity.

ES_SERVER
The default server name (used if no -r switch is specified on casstart or casstop).

Syntax

ES_SERVER=name

Values

  • name The server name.

Default

ESDEMO/ESDEMO64

ES_SSTM_CICS
Location of the JCL used to initialize the SSTM CICS environment
ES_SSTM_IMS
Location of the JCL used to initialize the SSTM IMS environment.
ES_SSTM_JOB_FLUSH_ACTIVE
By default, this is set to N. When set to Y, it causes a CICS SSTM job to be removed from the ACTIVE queue when the region shuts down.
ES_SURROGATE_JOB_USER
Associates a user ID with a job when submitting the job for processing through the internal reader from CICS.

Syntax

ES_SURROGATE_JOB_USER=value
Values

Any value - The user ID that started the ES region is used in the job submission.

Default

By default, the CICS default user CICSUSER, or as specified by ES_USR_DFLT_CICS, is used in the job submission.

ES_SYSOUT_HOLD
The status of the SYSOUT files are set to Out Hold.
ES_TMC_AGGREGATE
Controls the performance environment for IMS TM data stores. See ES_TMC_AGGREGATE in Environment variables in alphabetical order for details.

Syntax

SET ES_TMC_AGGREGATE={[,N|,D]|nnn,Y}

Values

,N
Sets the default behavior, which is to unilaterally flush operating system buffers to your physical disk at each key transactional point. While this does not change the method used by default at startup, it does enable dynamic modification via ESMAC. Once set, you can then test the effect of various non-default settings by altering them dynamically.
,D
Disables the transactional flushing of operating system buffers to disk. This option can significantly enhance message queue performance; however it is at the expense of the transactional integrity of the message queue in the event of a system failure.
Note: To avoid unpredictable results when using this setting, we highly recommend that you also set the static options as follows on the Administration Server > Properties > MSS > IMS > TM > General tab:
  • Set Cold start to Everything (queue)
  • Check Persist

See Server Instance Properties: MSS IMS TM General for details.

nnn,Y
Enables the aggregated transactional flushing of operating system buffers to disk where nnn represents an interval of time, in milliseconds, during which additional buffers are allowed to accumulate before flushing. Valid values are 0 through 255.

Once a thread reaches a key transactional point and requests a flush, TM waits the specified interval to accumulate subsequent threads that also request a flush. At the end of the interval, one flush is performed for all accumulated requests thus potentially improving performance by reducing the number of flush commands issued to the operating system.

Note:
  • Threads requesting a flush wait until the flush is confirmed.
  • Generally, when the message queue resides on a higher performance I/O subsystem such as one using SSDs, a smaller value, e.g. 1 or 2, produces the best results. A value of 10 or higher seldom improves performance.

Default

,N

ES_TN3270_FORCE_ALT
Enables you to use a screen size other than the default when using a TN3270 terminal emulator.

Syntax

SET ES_TN2370_FORCE_ALT=value

Values

  • Any value

Default

The default screen size is used.

ES_TN3270_MODEL_LOG
Writes the TN3270 emulator's model name to a temporary storage queue named TN32MODL that can be viewed using the CEBR transaction.

Syntax

SET ES_TN3270_MODEL_LOG=value

Values

  • Y|y - Model names are written to TSQ TN32MODL.

Default

Model names are not logged.

ES_TEST_TRANCLASS
Activates transaction class support.

Syntax

ES_TEST_TRANCLASS={Y|N}

Values

Y Activate transaction class support
N Do not activate transaction class support

Default

N, no transaction class support.

ES_TRANCLASS_CWI
For CICS Web Services, enables the prioritizing and limiting of Web requests in a TRANCLASS-enabled region.

Syntax

ES_TRANCLASS_CWI={TCPIPSERVICE|URIMAP}

Values

TCPIPSERVICE Prioritize and limit TCPIPSERVICE transactions
URIMAP Prioritize and limit URIMAP transactions

Default

TCPIPSERVICE

ES_TRX3650
The default transaction to run after a successful sign-on to IMS. See ES_DFS3650.

Syntax

SET ES_TRX3650=transaction

Values

  • transaction The default transaction to run.
ES_USR_DFLT_CICS
Allows you to override the default user when no user is logged on for CICS authentication.

Syntax

SET ES_USR_DFLT_CICS=user

Values

  • user - the default user name.

Default

CICSUSER

ES_USR_DFLT_ESMAC
Allows you to override the default user when no user is logged on for ESMAC authentication.

Syntax

SET ES_USR_DFLT_ESMAC=user

Values

  • user - the default user name.

Default

mfuser

ES_ESM_DISABLE_DFLTUSER_ESMAC
Allows you to disable the default ESMAC user in order to increase the security of your server. Disables the DEFAULT button on the logon screen and forces users to always enter a valid userid and password.

Syntax

ES_ESM_DISABLE_DFLTUSER_ESMAC=value

Values

  • Y|y - Default ESMAC user is disabled.

Default

Default ESMAC user is not disabled.

ES_USR_DFLT_IMS
Allows you to override the default user when no user is logged on for IMS authentication.

Syntax

SET ES_USR_DFLT_IMS=user

Values

  • user - The user name to override the default.

Default

IMSUSER

ES_USR_DFLT_JES
Allows you to override the default user when no user is logged on for JES authentication.

Syntax

SET ES_USR_DFLT_JES=user

Values

  • user The deafult user name.

Default

JESUSER

ES_XA_ABEND
Recycles non-batch SEPs when a severe error is returned by an xa-start by an Oracle switch.

Syntax

ES_XA_ABEND=RECYCLE

Default

None

ES_XA_LOG_SUPPRESS
Suppresses XA logging and the recovery of in-doubt XA transactions.

Syntax

ES_XA_LOG_SUPPRESS=value

Values

  • Y|y - XA logging is suppressed.

Default

By default no value is specified and XA logging is not suppressed.

ES_XA_RECONNECT
Set this to configure the XA reconnect process to operate in a single attempt mode. It takes two values separated by a comma.

Syntax

SET ES_XA_RECONNECT=Y,<seconds>

For example:

ES_XA_RECONNECT=Y,120
If the first value is set to Y this indicates that the reconnect process is required. The second is the number of seconds delay before the XA recovery transaction is triggered after a two-phase commit failure.
Note: The maximum delay you can specify is 300 seconds.

Default

If this variable is not set than the default is that the XA reconnect feature is not enabled.

ES_EZASOKET_SUPPORT (deprecated)
Switches on EZASOKET support.
Note: ES_EZASOKET_SUPPORT is deprecated, and provided for backward compatibility only. We recommend that you configure EZASOKET by using Enterprise Server Administration instead.

Syntax

SET ES_EZASOKET_SUPPORT=value

Values

  • Y|y - EZASOKET support is enabled.

Default

By default no value is set and EZASOKET support is not enabled.

ES_ZOS_SYSPRINT_DCB [16]
Enables MFJAMS SYSPRINT to have the same DCB attributes as the IDCAMS SYSPRINT.
Syntax
ES_ZOS_SYSPRINT_DCB=value
Values
  • Y|N - Set to Y to enable MFJAMS SYSPRINT to use the same DCB attributes as the IDCAMS SYSPRINT.
Default
ES_ZOS_SYSPRINT_DCB=N
EXTFH
Specifies a configuration file for the Callable File Handler.

Syntax

SET EXTFH=filename.cfg

Parameters

filename.cfg The name of the configuration file.

Example

SET EXTFH=/home/mydir/myconfig.cfg

F

FHREDIR
Specifies a configuration file to be used by the Fileshare Client.

Syntax

SET FHREDIR=filename.cfg

Parameters

filename.cfg The name of the configuration file.

Example

SET FHREDIR=/home/mydir/myconfig.cfg
FS

Specifies a configuration file to be used by the Fileshare Server.

Syntax

SET FS=filename.cfg

Parameters

filename.cfg The name of the configuration file.

Example

SET FS=myconfig.cfg
FSCOMMS
Specifies that the Fileshare system is to run in single user mode.

Syntax

SET FSCOMMS="\$local"

Parameters

"\$local" Run the Fileshare System in single user mode.

G

GDG_RESTART_UCC11_ONLY
Determines when GDG restart information should be written.

Syntax

SET GDG_RESTART_UCC11_ONLY=Y|N
Parameters
Y
GDG restart information is written, but only when ES_JES_RESTART=Y and MF_UCC11 is set (Y, YA, or M). This is the default.
N
GDG restart information is written even if MF_UCC11=N or is not set. (ES_JES_RESTART=Y must still be set.)

H

HCOBND (deprecated)
Specifies a directory to be used for bind files generated by the DB2 External Compiler Module (ECM).
Note: HCOBND is deprecated, and provided for backward compatibility only. We recommend that you use either the BIND or the BINDDIR compiler directive option instead.

Syntax

SET HCOBND=pathname
HCOBND=pathname
export HCOBND

Parameters

pathname The directory that the DB2 ECM is to use to store bind files.

Example

SET HCOBND=d:\mydir\binds

Comments

The DB2 ECM uses the specified directory until the variable is unset or reset to a different directory. The DB2 Compiler directive option BIND overrides this environment variable.

I

ICONN1
Controls the client TCP connection status of an IMS Connect emulator.
IMSCPY
The location of copybook files for DBDGEN, PSBGEN and MFSGEN utilities .
ISPPROF
The location of ISPF dialog profiles.

J

JAVA_HOME
Specifies the location of the JDK.

L

LIB
The location of the DB2 LIB directory

M

MAINFRAME_FLOATING_POINT
Specifies the format to use for floating point data items. Possible formats are IBM hexadecimal and IEEE.

Syntax

SET MAINFRAME_FLOATING_POINT=fpstatus

Parameters

fpstatus Which format to use for floating point data items. This must be one of:

  • true Specifies that IBM hexadecimal format floating point data items are to be used.
  • false Specifies that IEEE format floating point data items are to be used.

Setting MAINFRAME_FLOATING_POINT to anything other than true has the same effect as setting it to false.

The setting of this environment variable can be overridden by the NATIVE-FLOATING-POINT directive.

MF_ALIAS
Specifies program aliases. Each set (pair) is 16 characters long - 8 characters for the program-name, and 8 characters for the alias. You can specify up to 10 pairs. This list is searched first and thus can potentially override the built-in list. If not found, the built-in alias table is searched.
MF_AMODE31ONLY
Indicates that all programs are AMODE(31).
MFCATMNTUE

Specifies the name of the MFCATMNT user exit program if not compiled to the default name of MFCATMNTUE.

Syntax

SET MFCATMNTUE=program-name

Values

program-name represents the name of the MFCATMNT user exit program if not compiled to the default name of MFCATMNTUE.

Default

MFCATMNTUE=MFCATMNTUE

MF_CBLQDA
Determines if QSAM files are dynamically allocated when processing an OPEN I-O or OPEN EXTEND statement for an optional file (that is, a file opened using the SELECT OPTIONAL syntax in the FILE-CONTROL paragraph) or a file opened for OUTPUT (regardless of whether it is optional or not). Permissible values are OFF and ON; the default is OFF, which specifies that dynamic allocation is not permitted.
This is an emulation of the CBLQDA Language Environment (LE) run-time option.
When set to ON, and your JCL contains a misspelled or no DD statement for the file being opened, a temporary file is created as a result of the OPEN statement, and then deleted after the program has run. For optional files opened for I-O or for EXTEND, you receive a return code of 05; for files opened for OUTPUT, you receive a return code of 00.
This variable has no effect on VSAM applications or the JCL utility programs.
Note: For programs that use ESDS files and have this variable set ON, ensure that FILETYPE is set to 15 or 16; otherwise these files will be affected by the variable, and treated as QSAM files.
MF_CHARSET
Specifies the system character set (ASCII or EBCDIC).
MF_DUPJOBS
Enables jobs with identical names to run.
Values:
  • Y
  • N (Default)
MF_FALLTHRUCHECK
Specifies that MSS is to check that the main COBOL program ends by executing a GOBACK or STOP RUN.
Values:
  • y (default)
  • n
MF_JCL_AUDIT
Specifies that the audit log records audit information when a catalog entry is deleted.
Values:
  • DLET - Logs audit information each time an ESMAC/CAS utility deletes a catalog entry
  • DLEJ - Logs audit information each time a step in a JCL job deletes a catalog entry
  • DLET,DLEJ - Logs audit information each time either an ESMAC/CAS utility or a JCL job step deletes a catalog entry
MF_JES_ABEND_CAF_COMMIT [4]
Specify the outcome when a non-zero return code is received from the commit at the end of a DSNAL or IKJEFT** unit of work.
Syntax
MF_JES_ABEND_CAF_COMMIT=value
Value

value can be one of:

  • Yes - an abend (S482) is generated.

  • No - an abend is not generated.
  • rtn-code - a numeric value (up to 3 digits) to be used as the return code.
Default
Yes.
MF_MFA
Specifies what dataset catalogs are to be searched.
Values:
  • ALL - Search for datasets first in the local catalog, and if not found, on the mainframe (default)
  • RJSE - Search for datasets in the local catalog only. No mainframe is performed.
MF_MVSJOB
Sets the number at which a job starts and finishes.
MF_MVSJOB=<lower value>{-|+}<upper value>
Where:
<lower value>
Number at which a job starts. Contains 7 digits - for example, 0000001
-
Sets the values but only on the first startup of the region.
+
Reset the values to these new ones each time the region is started.
<upper value>
Upper job number. Contains 7 digits - for example, 9999999
For example:
set MF_MVSJOB=0000010+0000100
This resets the values to start with job number 10 and run through to job number 100. When the upper limit has been reached you receive a message:
All job numbers in the range 0000010:0000100 are in use
At this point you need to remove some jobs from the spool - you can use the spool housekeeping functions to do this.

This environment variable can be used to enable a 7-digit Job number limit. If the <upper value> mentioned is greater than 99999, then 6+ digit job number support is enabled. The maximum value that can be set is 9999999.

Tip: To revert to 5-digit job number support, set MF_MVSJOB=<low number>+<high number>, where high number is less than 0099999, and ensuring that the + sign is used to separate the low and high values.

If a value set using this variable is not valid, the default values of <0001000>{-|+}<0099999> are set.

MF_NEWSPACE
Indicates whether SPACE is required for NEW datasets.
MF_PCRENAME_LAX
When an MVS dataset is renamed, the associated physical file is normally renamed only if it is in the Default Allocation Dataset Location (which is the default, MF_PCRENAME_LAX=N). Set MF_PCRENAME_LAX to Y to enable physical files in other locations to be renamed if the cataloged name is changed. Set MF_PCRENAME_LAX to D to indicate that a new directory structure and filename will be constructed, and the existing file moved to that location.
MF_NODD
Specifies what action MSS is to take at run time if a job step uses a file that has not been allocated.
MF_RCCF
Enables Remote Job Step Execution (RJSE).
MF_ROOT_CERT
Enables the MF Directory Server process and any client applications to pick up the value of the root certificate file.
MF_SMS
Enables SMS support
MF_SPOOL_ARCHIVE_LOC
The base location for files archived as part of the spool housekeeping process, where the contents of the MVS SPOOL spool file are archived prior to deletion.

Syntax

SET MF_SPOOL_ARCHIVE_LOC=file-location

Values

file-location The file location.

MF_SPOOL_HK_LEX_SCAN

Determines if the MFELX* files associated with a job are also deleted when spool housekeeping is run.

Syntax

SET MF_SPOOL_HK_LEX_SCAN=Y|N

Values

Y The files are deleted.

N The files are not deleted.

Default

The default is Y.

MF_SPOOL_HK_OUTPRT
Determines if files from the Complete queue with a status of Output or Printed are also deleted when spool housekeeping is run.

Syntax

SET MF_SPOOL_HK_OUTPRTC=value

Values

Y Files from the Complete queue are deleted.

NFiles from the Complete queue are not deleted.

Default

The default is Y.

MF_SPOOL_HK_TESTDATE
Overrides the normal date for the spool housekeeping.

Syntax

MF_SPOOL_HK_TESTDATE=YYYYMMDD

Values

YYYYMMDD The date which is to override the normal date.

Default

If this variable is not set, the normal date for the spool housekeeping is used.

MF_SPOOL_HK_WRITE_PROFILES
Determines the creation of profile files (.PRO files) when a data set is archived.

Syntax

SET MF_SPOOL_HK_WRITE_PROFILES=Y|N

Values

Y Profile files are created.

N Profile files are not created.

Default

The default is Y.

MF_SYSLOGDSN
The Syslog Dataset name.
MF_UCC11
Note: This environment variable works independently of the JCL RESTART parameter.

Enables emulation of UCC11, a third party add-on to the mainframe that affects data set disposition processing.

MF_UCC11=Y|YA|M|MA|MR|N
  • Y - When restarting a job with DISP=(NEW,CATLG), it will not result in job failure caused by the data set already being cataloged.
  • YA - When running a job with DISP=(NEW,CATLG), it will not result in job failure caused by the data set already being cataloged.
  • M, MA, MR - When restarting a job any data set that has an initial disposition of NEW is changed to MOD. Therefore, data will be appended to the data set if it already exists.
  • N - MF_UCC11 is not set so a data set with an initial disposition of NEW may cause an error when restarting the job if the data set already exists.

The setting of the MF_UCC11 value can be made on a job-by-job basis using either the JCL user exit, MFJUXIT, or the Advanced Restart Functionality.

MF_USESCA5
Specifies that the server should use version 5 of the Open Service Component Architecture.
Values:
  • ON (Default)
  • OFF
MF_USESCA7
Specifies that MSS accepts CA7 Scheduler control statements as comments rather than diagnosing them as errors.
Values:
  • ON (Default)
  • OFF
MFALLOC_DEF_VB_PCFILE
When set to Y (the default), a new PS VB file that is created without an LRECL setting (or set to 0), is defined in the catalog as a VB file with default settings of minimum length = 0, and maximum length = 32760. Alternatively, set this variable to 'N' to ensure that the file is not created in these circumstances.[8]
MFALLOC_LOC
The default allocated data set location.
For a database-hosted data set location, you need to include the full SQL URL, for example, set MFALLOC_LOC=sql://localhost/JCLTEST?folder=/JCLDEMO/data
MFALLOC_PCFILE
When set to Y, which is the default, it will cause a catalogued file to be physically created if DSORG=PS is specified in the relevant DCB parameters.
MFALLOC_PROP
Rules for generated PC dataset names on allocation (that is, the default catalog PC DSN format).
MFAUDIT_LOGS
The location of audit files.
MFCODESET
Specifies which translation tables to use.
Values
  • A pre-defined country code:
    Important: To specify a Euro codeset, meaning that it includes the Euro symbol (€), prefix an "E" to the appropriate country code listed below. A country code with no "E" prefix indicates a non-Euro code.

    Country Code

    (MFCODESET)

    EBCDIC CCSIDs Language
    AUTOMATIC

    AUTO

    Operating system default - sets country code based on CBL_GET_OS_INFO
    DEFAULT Set to 0437 (US English) on Windows, or 0081 (Japanese Katakana Extended) on Japanese Windows.
    0031 37, 1140 Dutch
    0033 297, 1147 French
    0034 284, 1145 Spanish
    0039 280, 1144 Italian
    0043 273, 1141 German (Austrian)
    0044 285, 1146 UK English
    0045 277, 1142 Danish
    0046 278, 1143 Swedish
    0047 277, 1142 Norwegian
    0049 273, 1141 German
    0066 838 Thai Extended
    0081† 930 (290, 300) * Japanese Katakana Extended
    0082 933 (833, 834) *Korean
    0086 13676 (836, 837) *Simplified Chinese
    0351 37, 1140 Portuguese
    0358 278, 1143 Finnish
    0420[4] 420 Arabic

    See Arabic Support Considerations below.

    0437 37, 1140 US English
    0500 500, 1148 International (Latin 1)
    0886 937 (37, 835) *Traditional Chinese
    0930 † 930 (290, 300) *Japanese Katakana Extended
    0939 † 939 (1027, 300) *Japanese Latin Extended
    9122 † 9122 (290, 300) *Japanese Katakana

    Character sets marked with an asterisk (*) are capable of mixed single-byte and double-byte character translation. EBCDIC CCSIDs in these rows indicate the mixed-byte CCSID first, followed by the single-byte, then double-byte Code Page Global Identifiers (CPGIDs) in parenthesis.

    Other EBCDIC CCSIDs in parentheses reflect a 'non-Euro, Euro' pair for appropriate country codes.

    For database applications using a DBMS server on Windows, use the table above.

    For database applications accessing a UNIX database created with single-byte character sets 819 or 923, use the following table:
    Country Code

    (MFCODESET)

    EBCDIC CCSIDs Languages
    1140 37,1140 Dutch US English Portuguese
    1141 273,1141 German (Austrian) German
    1142 277,1142 Danish Norwegian
    1143 278,1143 Swedish Finnish
    1144 280,1144 Italian
    1145 284,1145 Spanish
    1146 285,1146 UK English
    1147 297,1147 French
    1148 500,1148 International (Latin 1)
  • A code between 2000 and 9999 (except 9122) corresponds to a user-defined translation table. User-defined tables are created using the Codecomp utility.

If you are not using UK or US language settings, you must also set the codepage in your PC environment settings:

  • Right click My Computer.
  • Select Properties.
  • Click Advanced system settings.
  • Click Environment Variables.
  • Under System Variables click New.
  • Enter MFCODESET as Variable name and XXXX as Variable value, where XXXX is your chosen codepage.
MFCODESET_DBCSDIR
Set this variable to the location of a set of mapping files (.E2A and .A2E files) required for an application to perform ASCII/EBCDIC conversions of certain double-byte character sets.
If this variable is not set, the application looks in the etc/codeset sub-directory of the product installation directory to locate the files required for the inbuilt support. (The support covers codesets 81, 82, 86, 886, and 941.)
However, certain deployed applications do not require a full Enterprise Server product to be available (for example, .NET COBOL applications, JVM COBOL applications, and native self-contained applications), and so cannot utilize the inbuilt translation support provided by a full product. In these cases, you must deploy the mapping files with the application, and use this variable to locate the files at run time. You only need to deploy the .E2A and .A2E files appropriate to the codeset(s) you require.
MFCSCFG
Specifies a configuration file to be used by the Client/Server Binding client program.

Syntax

SET MFCSCFG=filename

Parameters

filename The name of the configuration file.

Example

SET MFCSCFG=/home/mydir/mfclisrv.cfg

Comments

The value of MFCSCFG is overridden by any value defined in the command line. If neither of the above yields a filename, the default filename mfclisrv.cfg is assumed, and is searched for in the current directory. If that in turn is not found, the default settings for the configuration entries are used.

MFDBFH_CONFIG

Specifies the location and the name of the configuration file that defines the database server instances and associated databases.

Syntax

SET MFDBFH_CONFIG=value

Values

value represents the full path and filename of your database configuration file.

Default

Not set.

MFDBFH_RECORD_LOCKING

Specifies the type of record locking that it is to be used when the database file handler is in effect.

Syntax

SET MFDBFH_RECORD_LOCKING=table|database

Parameters

table
A file's record locks are held in a seperate lock table. (When using this locking mode, the behavior of record locking COBOL file operations closely follows the same behavior when using Fileshare.)
database
The native record locking mechanism of the database engine is used to establish and test locks on the data file records. This method improves performance, but at the cost of the locking behavior not exactly matching that of traditional COBOL record locking; see Record Locking Strategies for more information.

Default

MFDBFH_RECORD_LOCKING=table
Note: If the value of this variable is set to anything other than 'database', this default is used.
MFDBFH_SCRIPT_DIR

Specifies the location of the scripts and stored procedures required when the database file handler is in effect.

Syntax

SET MFDBFH_SCRIPT_DIR=value

Values

value represents a path to the directory containing the required resources.

Default

value defaults to the \etc\mfdbfh\scripts sub directory of your product installation directory.

MFDBFH_VAULT
Specifies the name of a secrets vault (which must be defined in the product's secrets.cfg file). If this environment variable is not set, MFDBFH uses the default vault, as defined in secrets.cfg.

For more information on secrets vaults, see Vault Facility.

Syntax

SET MFDBFH_VAULT=value

Values

value represents the name of a vault.

Default

Not set.

MFE.SMS
Enables SMS support.
MFFTP_ASCII_CMD_XLATE

For EBCDIC datasets, translates from EBCDIC to ASCII using a PUT, and ASCII to EBCDIC using a GET.

Syntax

MFFTP_ASCII_CMD_XLATE={Y|N}
Parameters
Y
Converts from EBCDIC to ASCII in PUTs and from ASCII to EBCDIC in GETs, for files cataloged as EBCDIC when TYPE A or ASCII sub command is also issued.
N
Standard conversion. Default.

Comments

When set to Y, must be used with TYPE A or ASCII sub command.

MFEXTMAP
Location of a mapper file.
MFIMS_ACBDUMP_TIMESTAMP
Suppresses date/time stamp display in ACB report.
MFIMS_BMPCHKP
Returns a QC to a checkpoint call when it the call includes an IO area.
MFIMS_DIBSTAT_CODES
Specifies additional DIBSTAT return codes to be returned to EXEC DLI program.
MFIMS_DLI_OPT
Specifies DL/I call optimization flags.
MFIMS_DIAG
Enables IMS BTS format diagnostic tracing.
MFIMS_FLUSHTRACE
Flushes BTS trace file to disk after every write.
MFIMS_FP_DA
Bypasses keycheck on IMS Fastpath DB delete.
MFIMS_LOADMVS
Disables load of MVS support for IMS application programs.
MFIMS_PCBCALL
Allows a standalone EXEC DLI program to issue a PCB call.
MFJ_ALL_STEP_CHECK
The default behavior of this product is to not check COND CODES from steps prior to a restart step. This means that the steps after the restart step that have conditions that refer to any steps prior to the restart step might run. This is a change of behavior from releases 4.0 Patch Update 1 and earlier when these steps would have not run. Micro Focus recommends that you review and test the behavior before restarting the jobs.

Set this variable to Y to prevent steps after a restart step that have conditions that refer to any steps prior to the restart from running.

MFJ_PTPCH_CODESET[4]
For use when an extended Japanese code set other than 9122 is being used. This will cause MFJPTPCH to check the same hexadecimal character value as with code set 9122 to decide if a character is printable or not. The only permissible value is EXTJ:
MFJ_PTPCH_CODESET=EXTJ
MFJFAXIT
Specifies the user exit program that enables file action notifications. This user exit is called by the JCL engine whenever a JCL file is opened OUTPUT, I-O, or EXTEND, or when it is copied or renamed by the JCL engine. See User Exit for File Action Notifications for more information.
A sample user exit program (MFJFAXIT.cbl) is provided with your product, and is located in the src\enterpriseserver\exits sub-directory of your product install directory.
MFJFAXIT=<path-and-file-name-of-exit>
MFJ_INPUTDS_ERROR
When set to N, this will cause IEBDG, IEBGENER, IEBCOMPR, and DFSORT and ICETOOL emulation to treat missing files as though they were present but empty.
MFJSABCODE
Determines the abend (abnormal end) code issued when MFJSERET=ABEND is in effect. If a Sort or Merge operation fails with an unrecoverable error, it will abend with a code between S001 and S063.

Syntax

SET MFJSABCODE=code

Parameters

code A decimal value between 1 and 99 representing the abend code to be issued.

Any specified value outside of the range 1 to 99 will result in an abend code of S00D being issued.

Default

By default, this environment variable is not set. If so, and if MFJSERET=ABEND is in effect, an abend S00D (decimal code 16) is issued when a Sort or Merge operation fails with an unrecoverable error.

Example

MFJSABCODE=77

This example results in abend code S04D being issued.

MFJSENGINE
Specifies which sort engine the utility MFJSORT is to emulate.

Syntax

SET MFJSENGINE=value
Values:
  • DFSORT Emulates DFSORT
  • SYNCSORT Emulates SYNCSORT

Example

Default

The default is DFSORT.

MFJSERET
If this environment variable is not set, an unsuccessful operation and its program will terminate with an unrecoverable error (return code 16). See also MFJSABCODE.

Syntax

SET MFJSERET=ABEND

Parameters

ABEND The operation will abend and its program will continue instead of terminating with an unrecoverable error (return code 16)

Default

By default, this environment variable is not set.

MFJSSTRICTSORT
Enables or disables the following mainframe behavior:
  • All JCL statements must contain a SYSOUT parameter, otherwise they will abend.
  • Modification of a ZD number with value 0 through INREC or OUTREC processing now keeps its sign value.
  • Records that are shorter than the output file's LRECL will be padded with low-values instead of spaces.
  • Input RECFM is identical to the output RECFM or OUTFIL RECFM (unless FTOV or VTOF/CONVERT has been specified), otherwise it errors with return code 16.

Syntax

SET MFJSSTRICTSORT=ON|OFF

Default

The default is OFF.

Example

MFJSSTRICTSORT=ON
MFJSTATS

For a COBOL sort not running under mainframe emulation, setting the environment variable MFJSTATS to ON creates a report containing statistics for the SORT that is displayed to SYSOUT. If a report file already exists for a previous SORT, the new statistics are appended to the end of the previous one.

If you are performing a COBOL sort using mainframe emulation, you can create a statistics report by modifying the JCL statement.

Syntax

SET MFJSTATS=switch

Parameters

switch Switches report creation ON or OFF. The default is OFF.

MFJ_STRICT_CASE
Enables the case of physical file names passed to MVSCATIO by the catalog API (and other utilities such as MFCATXML and MVSPCRN) to be maintained. When set to N, all physical file names will be folded into upper case.
Syntax
SET MFJ_STRICT_CASE=Y|N
Default
the default is N.
MFJSWINDOW

Use this environment variable for Y2K compatibility, when two-digit year values are used.

Syntax

SET MFJSWINDOW=value

Values

To set a sliding century window, set a value between 0 and 100. For example, a value of 80 would set a century window of 1931-2030 in 2011, 1932-2031 in 2012, and so on.

To set a fixed century window, set a value between 1000 and 3000. For example, a value of 1973 would set a century window of 1973-2072.

Default

The default is a sliding value of 80 when emulating DFSORT, and a default value of 0 when emulating SYNCSORT. A value of 0 equates to a century window, starting in the current year.

Comment

You can use this environment variable instead of the Y2PAST sort option.

Example

MFJSWINDOW=25
MFLECONFIG

Specifies a configuration file for Language Environment (LE) runtime options.

Syntax

SET MFLECONFIG=filename

Parameters

filename The file containing the LE runtime options you want to use.

MFLOCKING
Enables Locking Support
MFLOGDIR
Specifies a directory to be used by Client/Server Binding for log files.

Syntax

SET MFLOGDIR=dirname

Parameters

dirname The name of the directory for log files.

Example

SET MFLOGDIR=/home/mydir/logs
MFPLI_PRODUCT_DIR
The location of the Open PL/I installation. Used to find files needed for compiling and linking.
MFPRELOAD_USE
Calls MFPRELOAD to improve performance.
MFREXX_LSEQ_RECSIZE_MAX

Specifies the record length for the REXX EXECIO command when reading or writing a line sequential file that has been cataloged with a record length of zero.

Values:
  • Record length to use (Default = 255)
MFREXX_NO_PROCESS_STDIN[10]
When set to "y" or "Y" this environment variable stops STDIN from being processed on an EXECIO command.
MFREXX_NOT
Specifies one or more characters to be used for the NOT operator in addition to REXX's default, which is "¬".
Values
  • One or more characters for each operator; each character you specify is used in addition to the default operator. Each additional character must be defined within single or double quotes, or in hexadecimal. Separate multiple characters with a space or a comma.
MFREXX_OR
One or more characters to be used for the OR operator in addition to REXX's default, which is "|".
Values
  • One or more characters for each operator; each character you specify is used in addition to the default operator. Each additional character must be defined within single or double quotes, or in hexadecimal. Separate multiple characters with a space or a comma.
MFRU_NOINHERIT
Determines if processes are registered in shared memory during initialisation of the run-time system. COBRT105 errors can occur during initialisation if a very large number of COBOL processes are running and there are no available slots in the shared memory segment - setting this variable to Y or TRUE skips the registration process. However, when set to Y, various run-time settings (switches, shared memory, console window settings, etc...) are no longer inherited by any child processes.

When the variable is not set (which is the default), the registration process is not skipped.

Syntax

SET MFRU_NOINHERIT=Y|TRUE

The default is that the variable is not set.

MFSUB
Specifies whether to use SUBI or ASUBI.
Values
  • SUBI
  • ASUBI
MFSYSCAT
The location and file name of the JES system catalog.
Syntax
SET MFSYSCAT={path\CATALOG.DAT | URL}
Parameters
path
The full path to the location of the CATALOG.DAT file.
URL
For a database-hosted system catalog, the full SQL URL that points to the CATALOG.DAT file.
Examples
SET MFSYSCAT=C:\MY\CATALOG\FOLDER\CATALOG.DAT
SET MFSYSCAT=sql://localhost/JCLTEST/catalog.dat?folder=/JCLDEMO
MFSYSCATDIR
The location of the system catalog directory.
MFTRACE_ANNOTATIONS
The location of the trace files.
MFTRACE_CONFIG
The location of the CTF configuration file.
MFTRACE_LOGS
The location of the CTF log files.
MFTSO_DEBUG
Controls the display of debug messages.
MFUSER
The default User ID.
MFUSERCAT_LOC
User catalog location
MQSERVER
The location of a WebSphere MQ Server installation.
MULTMFENTMAP
Specifies whether special characters such as < and & are replaced with the equivalent HTML entities (for example &lt; and &amp;).

O

OOSW
OO run-time switches.

P

PROCLIB
When set to ON and under a mainframe emulation, a file status of 37 is returned when you open an existing VSAM file for OUTPUT and the file has or previously had some data written to it, or if the file format is different from the file on disk. The default for this variable is OFF.

R

RANDOM
If using SSL connections, externally generated random data that is stored as a numeric value in the RANDOM variable will be inserted into the initial salt value used to generate temporary key pairs used in SSL hand-shaking. The RANDOM value will only form part of the initial salt value and is an aid to generating more randomness and not an essential requirement.

S

SORTCOMPRESS
Tells the system whether or not to execute a compression routine on each record to be sorted.

Syntax

SET SORTCOMPRESS=n

Parameters

n - An integer that indicates if compression is enabled or not. 0 (zero, the default) indicates not enabled; any positive integer indicates enabled. When enabled, it allows for run-length encoding of sort records, resulting in much better performance when records contain multiple repeated characters.

Comments

This variable is recommended if the sort records contain many single repeated characters, for example, multiple spaces, as it can be very effective in improving memory usage and therefore sort performance.

Example

SET SORTCOMPRESS=5
SORTSCHEME
Activates a sortscheme. Use in conjunction with SORTSPACE for improved performance.

Syntax

SET SORTSCHEME=1
Values
  • SORTSCHEME=1 - this is the only valid value for the environment variable. See SORTSPACE for more information.
SORTSPACE
The amount of memory to be allocated to internal workspace for SORT operations. This can be specified in different formats: for example, you could specify 64M, 2G, and 1000000 to give sort memory areas of 64 Megabytes, 2 Gigabytes and 1000000 bytes respectively.

Syntax

SET SORTSPACE=n[K|k|M|m|G|g]

Parameters

n[K|k|M|m|G|g The amount of memory to be allocated to internal workspace for SORT operations. K or k indicates kilobytes, M or m indicates megabytes and G or g indicates gigabytes. No letter indicates bytes. Defaults to 1 megabyte.

Comments

A larger value for SORTSPACE will generally result in a faster sort. However, if you specify a value that exceeds the capacity of main memory in your computer, such that the operating system has to page memory in and out, performance will be degraded.

Example

SET SORTSPACE=1024K

SORTTEMPSPACE
Specifies the amount of memory to be allocated to temporary workspace for SORT operations.

Syntax

SET SORTTEMPSPACE=n[K|k|M|m|G|g]

Parameters

n[K|k|M|m|G|g] The amount of memory to be allocated to temporary workspace for SORT operations. K or k indicates kilobytes, M or m indicates megabytes and G or g indicates gigabytes. No letter indicates bytes. 32 megabytes is the lowest amount of memory that can be allocated.

Comments

The memory allocation strategy used by SORT can be adjusted through use of SORTTEMPSPACE, which generally improves performance in systems suffering from memory fragmentation.

Example

SET SORTTEMPSPACE=250MB
SORTTYPE
Defines the sort type.

Syntax

SET SORTTYPE=2
Values
  • SORTTYPE=2 Forces SORT to use the file handler, so that format modifications are picked up from the extfh.cfg file.
  • Not setting this variable means that SORT will try to use CBL_ routines to read and write files to improve performance.
Note: 2 is the only valid value for this environment variable.
SSLDIR
If using SSL connections, this value specifies the generic location of the system's OpenSSL directory.
SSTM_WC_REFRESH
Determines how often the write count for the SSTM job is updated in SYSOUT or SYSPRINT. You can set a value between 1-65535 to indicate the number of writes at which the count is updated. A value of 0 (zero) indicates that the count is only updated when the file is closed. Any other value smaller that 1 will default to 0, and any value larger than 65535 will default to 65535.
STEPLIB
The paths for Loader input load-members .390 files (must contain SYSLMOD) .
Note: For this environment, you can specify multiple paths, each separated by a semicolon.

T

TX_MQ_CONVERT

TX_MQ_CONVERT is used to overwrite the MQ queue manager CCSID.

If the variable is not set, Enterprise Server will use the current queue manager CCSID.

The value is used in the MD-codedcharsetid parameter.

TX_MQTRACE
Enables tracing in dfh0mqis for WebSphere MQ calls.
TX_TN3270_FORCE_ALT
Enables you to use a screen size other than the default when using a TN3270 terminal emulator.
TXFILEP
The location of Micro Focus VSAM files. This can be a location on disk or a datastore location within a database. For database-hosted files, use the notation sql://host[/instance]/datastore[?folder=/path] - see The dbfhdeploy Command Line Utility for more information.
TXMAPP
The location of the BMS load module.
TXRDTP
The location of MSS resource definition (RDO) files.
TXTRANP
The location of the CICS application object files.

U

USSCONFIG
Use this variable to point to the location of the SSL cipher suite specification file(s) used by the CIPHERS attribute in the CICS URIMAP or TCPIPSERVICE resource.

The CIPHERS attribute in these CICS resources (which is for USAGE(CLIENT)) can be specified in one of the following ways:

  • A string of up to 56 hexadecimal digits that is interpreted as a list of up to 28 2-digit cipher suite codes.
  • The name of the SSL cipher suite specification file name can be up to 28 characters long including the extension which must be .xml. The file name can only contain the characters A-Z a-z 0-9 # - . @ _.
Syntax
SET USSCONFIG=/absolute/path/to/cipher/suite/specification/file(s)

V

VSE_STARTUP_CFG
The location of the VSE JCL configuration file

X

XFHLOG
Determines the location of the log file when the LOG option is active.

Syntax:

SET XFHLOG=DEFAULT

Parameters:

DEFAULT - generates the log file in the current directory.

Comments:

If the XFHLOG variable is not set, the log file is created in C:\ProgramData\Micro Focus\File Handler\[version-number].

where [version-number] represents the version of your Micro Focus product.

The effect of this variable can be overridden by the LOGFILENAME configuration option.
